AUTOOL AST605 Pulsating Brake Fluid Exchanger
US$239.00
主要特色
- One-Person Pulsating Exchange
- 0.7–3 Bar Control
- DOT3 / DOT4 / DOT5.1
- Integrated Used-Fluid Recovery
- One-Person Pulsating Exchange: Run brake-fluid replacement with one operator after the bottle, hoses, adapter, and pressure are prepared.
- 0.7–3 Bar Control: Set and monitor working pressure from 0.7 to 3 bar (±0.2 bar) with the front knob and gauge.
- DOT3 / DOT4 / DOT5.1: Use the machine with the vehicle-specified DOT3, DOT4, or DOT5.1 brake fluid.
- Integrated Used-Fluid Recovery: Collect old brake fluid in the recycle bottle stored inside the machine body.
- Air-Inlet Moisture Filter: Separate moisture at the air inlet before it reaches the fluid path.
- 3 年保用期 主機保固 3 年，配件保固 1 年
- 90日返回 符合條件的退貨可在 90 天內進行
- 官方店鋪 正品 · 直接支持
AUTOOL AST605 · Pneumatic Pulsating Brake Fluid Exchanger
Control Pulsating Service with Visible Pressure
AUTOOL AST605 supports one-person pulsating brake-fluid service with a visible pressure gauge and front adjustment knob. AST605 supports vehicle-specified DOT3, DOT4, or DOT5.1 fluid, collects used fluid in the integrated recovery bottle, and filters moisture from the pneumatic inlet before it reaches the fluid path.
- One-Person Pulsating Exchange
- 0.7–2.5 bar Listed Pressure
- Up to 1.5 L/min Flow
- DOT3 / DOT4 / DOT5.1
- Air-Inlet Moisture Filter
主要特色
Air-Powered Flow with Used-Fluid Recovery
Pulsating Fluid Exchange
Compared with conventional pressurized brake fluid bleeding, the pulsating exchange method helps reduce bubble formation during filling and can reduce the need for repeated manual venting.
One-Person Operation
After the brake fluid bottle, filling hose, recycle bottle, connector, and pressure setting are prepared, one operator can complete the brake fluid exchange process more efficiently.
Gauge-Guided Pressure Control
The filling pump includes pressure monitoring. Use the pressure knob and gauge to control working pressure during brake fluid replacement.
Automatic Protection Logic
If pressure cannot be established or the pump sucks in air, the machine can shut down automatically to help protect the system during operation.
Used Brake Fluid Recovery
The recovery function collects used brake fluid quickly. The recycle bottle can be placed inside the machine body for easier carrying and storage.
Moisture Filtering At Air Inlet
The air inlet includes a water separation and filtering device to help remove moisture from the air and reduce the chance of moisture mixing with the brake fluid.
Brake Fluid Compatibility
AST605 is compatible with DOT3, DOT4, and DOT5.1 brake fluid standards. Always follow the vehicle manufacturer’s required brake fluid type.
One-Person Pressure Control
AST605 supports one-person pulsating brake fluid exchange with an adjustable pressure knob and a gauge for monitoring working pressure.
Used-Fluid Bottle Storage
The recovery function collects used brake fluid, and the corrosion-resistant recycle bottle fits inside the machine body for carrying and storage.
Accessible Workshop Connections
Quick connectors, a hose hook, and the pressure gauge and knob keep setup and pressure adjustment within reach.
車輛覆蓋
Suitable for many European, American, and Asian vehicles when the correct adapter is used. Confirm compatibility for special reservoir designs before ordering.
3年保固支持
主機：三年保固。標準配件：一年保固。保固政策。
Service Workflow
Set Air Supply, Prime and Bleed
步驟進展1 / 7
01
Raise The Vehicle Safely
Raise the vehicle to a suitable height so the drive wheels are not on the ground and the brake caliper area is accessible.
02
Connect the Used Brake Fluid Side
Connect the used brake fluid recovery bottle or suction hose to the vehicle brake cylinder area, then loosen the bleed screw so brake fluid can flow out.
03
Prepare New Brake Fluid
Pour about 2L of new brake fluid into the equipment from the filler port, then connect the matching adapter to the brake master cylinder or reservoir.
04
連接電源
Connect the machine to the correct power supply version, then turn on the power switch.
05
Start Vacuum And Filling
Press the Vacuum Switch button, then press the Fuel Switch button to begin brake fluid exchange.
06
Monitor Flow And Finish
Monitor the brake oil tank during service. If refilling is too slow, use the acceleration switch; if it is too fast, use the deceleration switch. Drain used oil completely after service.
07
First-Use Line Priming
Fill and bleed the machine’s fluid line before first use, following the setup procedure before connecting for brake fluid exchange.
安全使用
Dry the Air, Seal the Reservoir and Limit Pressure
Use Safe Working Pressure
The AST605 supports adjustable pressure, while the factory reference working pressure is around 1-1.5bar. Avoid unnecessary high pressure because excessive pressure may damage the brake master cylinder or brake system parts.
Adjust Pressure Gradually
The pressure regulator can be used for lower-pressure bleeding or fluid exchange when needed. Increase pressure carefully and monitor the pressure gauge during operation.
Check For Leaks First
Before changing brake fluid, check every connection point for leakage and inspect hoses for damage. Keep the new oil filler port clean.
Prevent Air In The Line
During first use, fill the equipment line with brake fluid to evacuate air before service. This helps prevent air from mixing into the vehicle brake fluid line.
車輛覆蓋
Suitable for many European, American, and Asian vehicles when the correct adapter is used. Confirm compatibility for special reservoir designs before ordering.
Prime the Fluid Line
Fill the delivery line with the specified brake fluid and remove air before connecting it to the vehicle.
Seal the Reservoir
Choose the matching reservoir adapter and check the cap and hose connections for leaks before building pressure.
模型比較
Choose the Right Brake Fluid Bleeder
模型指南
Choose one or more models. AST605 is selected by default.
已選擇 1 個模型
未選擇任何型號。請選擇一個型號進行比較。
| 產品描述* | 穀草轉氨酶603 | 穀草轉氨酶605 | 穀草轉氨酶609 | 穀草轉氨酶612 | 穀草轉氨酶618 |
|---|---|---|---|---|---|
| Service Method & Capacity | |||||
| 工作原理 | Fully Automatic One-Click Pulsating Oil Change | Fully Automatic One-Click Pulsating Oil Change | Fully Automatic One-Click Pulsating Oil Change | Fully Automatic One-Click Pulsating Oil Change | |
| 油瓶 | 1L · 1 Used Oil Bottle | 1L · 1 Used Oil Bottle | 1.5L · 1 Old Oil Bottle 1L · 1 New Oil Bottle | 1.5L · 2 Old Oil Bottle 1L · 1 New Oil Bottle | 1.5L · 4 Old Oil Bottles 3L · 1 Integrated Stainless Steel Oil Bottle |
| Number of Brake Calipers | 1pc | 1pc | 2片 | 2片 | 4片 |
| Shutdown Pressure Relief Function | × | × | × | 30 Seconds Pressure Relief Time | 10 Seconds Pressure Relief Time |
| Number of Brake Caliper Changed Simultaneously | Single-Wheel Oil Change | Single-Wheel Oil Change | Simultaneous Oil Change for Two Wheels | Simultaneous Oil Change for Two Wheels | Simultaneous Oil Change for Four Wheels |
| Maximum Output Flow Rate | 1.6L /分鐘 | 1.6L /分鐘 | 1.6L /分鐘 | 2.6 升/分鐘 | 1.6L /分鐘 |
| 脈衝設定 | × | × | × | × | ✓ |
| Working Pressure Adjustment | ✓ | ✓ | ✓ | ✓ | ✓ |
| Working Time Settings | × | × | × | × | ✓ |
| Power, Pressure & Connections | |||||
| 輸入電壓 | AC 110/220 V or DC 12 V — match the selected power configuration | 110 / 220V | 110/220伏或12伏 | DC12V | DC12V |
| 工作壓力 | 0.5-2.5bar | 0.7-3bar(±0.2bar) | 0.5-2.5bar | 1.5巴-3.0巴 | 0.6-3.0bar |
| 相容連接器 | 1種 | 3類型 | 7類型 | 9類型 | 17類型 |
| 壓力計 | ✓ | ✓ | ✓ | ✓ | ✓ |
| Power Aviation Plug | ✓ | ✓ | ✓ | × | × |
| Mobility & Physical Setup | |||||
| 產品重量 | 5.2kg | 5.3kg | 7.4kg | 8kg | 23.5kg |
| 360° Casters | × | × | × | × | ✓ |
| Three-Section Telescoping Handle Design | × | × | × | × | ✓ |
手冊和支持
Find the Manual and Bleeding Guidance
AUTOOL AST605 User Manual
Open the PDF manual for AUTOOL AST605 pneumatic pulsating brake-fluid service, pressure adjustment, reservoir connection, fluid selection, moisture filtering, used-fluid recovery and troubleshooting support.
包裝內容
See What Comes in the Box
- 主機AUTOOL AST605 brake fluid bleeder
- 電力電纜電力電纜
- 軟管Filling hose, suction hose, and related connection hoses
- Brake Fluid BottleRecycle / used brake fluid bottle
- 適配器3 compatible connector types
- 文档User manual and retail box
買家問題
Bleeder Setup, Adapter and Fluid Questions
What Working Pressure Should I Use For AST605?
The factory reference working pressure is around 1-1.5bar to help prevent deformation of the liquid storage chamber and keep the secondary sealing ring tight. AST605 supports adjustable pressure, but avoid unnecessary high pressure because excessive pressure may damage the brake master cylinder or other brake system components.
Can AST605 Change Brake Fluid From Four Wheels At The Same Time?
No. AST605 is a single-wheel oil change model with 1pc brake caliper service. If you need two-wheel simultaneous service, compare AST609 or AST612. If you need four-wheel simultaneous brake fluid exchange, choose AST618.
What Brake Fluid Types Does AST605 Support?
AST605 is compatible with DOT3, DOT4, and DOT5.1 brake fluid standards. Always use the brake fluid type required by the vehicle manufacturer.
Do I Need To Start The Vehicle During Operation?
No. The vehicle does not need to be started during AST605 operation. Raise the vehicle safely, connect the hoses and adapter correctly, and operate the machine according to the service procedure.
Why Should I Fill The Equipment Line With Brake Fluid Before First Use?
Filling the line with brake fluid during first use helps evacuate air from the equipment line. This reduces the risk of air mixing into the vehicle brake fluid line during exchange, which could affect braking performance.
What Should I Check Before Changing Brake Fluid?
Check each connection for leakage, inspect whether any connecting hose is damaged, confirm the correct adapter is installed, keep the new oil filler port clean, and make sure the used-oil recovery path is connected correctly.
What Should I Do After The Oil Change Is Completed?
Drain the used oil in the equipment tank completely after service. If the used oil is not emptied, the vacuum pump may be damaged and the oil change operation may not be performed correctly next time.
Does AST605 Support 110V And 220V?
Order the AST605 voltage version that matches the workshop supply, then verify the voltage on the selected unit’s label before connection.
Which Connectors Are Included With AST605?
AST605 includes 3 compatible connector types. Adapter examples include #1 for many European, American, and Asian vehicle brands, #6 for Toyota series, and #16 for Tesla. Confirm compatibility before ordering if your vehicle uses a special brake fluid reservoir connector.
Which AST Brake Fluid Bleeder Should I Choose?
- Choose AST605 if you need a compact pulsating brake fluid bleeder with 3 connector types and single-wheel oil change.
- Choose AST609 if you need 7 connector types and two-wheel simultaneous service.
- Choose AST612 if you need DC12V operation and 9 adapter types.
- Choose AST618 if you need 17 adapter types, four-wheel simultaneous service, pulse settings, working time settings, wheels, and a telescoping handle.
保固期有多長？
主機：三年保固。標準配件：一年保固。保固政策。
