AUTOOL AS505 Optical Transmission Fluid Tester
US$49.00
Funzionalità principali
- Optical Transmission-Fluid Screening
- Photoelectric Transmittance Probe
- Temperature + Status Display
- 800 mm Flexible Hose
- Optical Transmission-Fluid Screening: Measure automotive transmission-fluid transmittance and temperature before maintenance decisions.
- Photoelectric Transmittance Probe: Use the photoelectric probe to screen changes in fluid transparency linked with impurities or deposits.
- Temperature + Status Display: View oil temperature, transmittance, an analog bar, and OK, warning, or replacement guidance on the 2.8-inch backlit screen.
- 800 mm Flexible Hose: Reach service points with the oil-resistant, oxidation-resistant Teflon probe.
☰ RICHIEDI UN PREVENTIVO PER ACQUISTI ALL'INGROSSO / B2BRichiesta di preventivo ufficiale
Caricamento del modulo di richiesta in corso...
- 3 anni di garanzia Unità principale 3 anni · Accessori 1 anno
- Resi entro 90 giorni Resi idonei entro 90 giorni
- Negozio ufficiale Prodotti originali · Assistenza diretta
AUTOOL AS505 · Transmission Fluid Transmittance Tester
Inspect ATF Condition with Optical Context
Screen transmission-fluid transparency and temperature before deciding the next maintenance step. AS505 uses a flexible 800 mm probe to reach service points and shows transmittance, an analog bar, fluid temperature, and status guidance on one backlit display. The optical reading is service context rather than a stand-alone replacement decision.
- ATF Transmittance Screen
- Fluid Temperature Context
- Sonda flessibile da 800 mm
- Display retroilluminato da 2.8 pollici
- 6 V Battery Power
Funzionalità principali
Transmission Fluid Tester: Transmittance and Temperature Together
High-Precision Optical Transmittance Probe
The integrated photoelectric transceiver sensor probe helps provide stable measurement feedback when checking transmission fluid transmittance.
800mm Flexible Hose Probe
The 800mm Teflon hose probe offers flexible access during testing and is resistant to oil, oxidation, and corrosion for longer service life.
Oil Temperature Display
The built-in temperature sensor displays the current transmission fluid temperature and supports °C / °F unit switching.
LCD retroilluminato da 2.8 pollici
The high-definition backlit LCD makes readings easier to view in daylight, dim workshop areas, or nighttime conditions.
Clear Result Indicators
The screen shows transmittance, analog bar graph, OK, warning, and suggested replacement indicators to help users interpret the result quickly.
Design ergonomico e comodo da impugnare
The silicone-lined handheld portion provides a comfortable grip, while the lightweight body supports easy single-handed operation.
Controlli del fluido di trasmissione
AS505 measures automotive transmission fluid transmittance and temperature.
Portable Battery Power
The 175 × 72 × 29mm tester uses four 1.5V batteries for 6V operation.
Transmission Fluid Testing
AS505 is mainly used to test automotive transmission fluid transmittance and oil temperature. Reduced transmittance may be related to impurities, deposits, or metal contamination in the fluid.
6V Battery Power
The tester uses 4 × 1.5V AAA batteries for a 6V operating voltage. Install batteries with the correct polarity before powering on.
Spegnimento automatico
The tester automatically powers off after about 5 minutes of no activity. Long press the power key to turn the tester on or off manually.
3 anni di garanzia e assistenza
Unità principale: 3 anni di garanzia. Accessori standard: 1 anno di garanzia. Politica di garanzia.
Flusso di lavoro del servizio
Reach, Read and Clean the Probe
Progresso graduale1 / 6
01
Install Batteries And Power On
Open the rear battery cover, install 4 × 1.5V AAA batteries with correct polarity, then long press the power key for more than 2 seconds.
02
Wipe The Probe Clean
Before each measurement, wipe the probe tip clean so old oil or dirt does not affect the transmittance reading.
03
Check Temperature Condition
Make sure the engine temperature is below 60°C. Press the temperature key if you need to switch between °C and °F.
04
Submerge The Probe
Place the testing probe into the transmission fluid. Keep the probe properly immersed during measurement.
05
Press Test And Read Result
Press the test button. The interface displays the transmission fluid transmittance and current fluid temperature.
06
Simple Sampling Procedure
Clean the probe, immerse it in the transmission fluid, then start the test and read the result.
Uso sicuro
Confirm Fluid Fit Before Testing
Engine Below 60°C
Before testing, make sure the engine temperature is below 60°C. This helps keep the measurement process within the recommended operating condition.
Suggested Test Interval
It is recommended to check transmission fluid condition every 5,000-10,000 km, especially before deciding whether transmission fluid service is needed.
Clean The Probe First
Wipe the test probe clean before each measurement. Residual oil, dirt, or contamination on the probe may affect the reading.
Utilizza i risultati per pianificare il prossimo controllo
Use the condition score to screen and compare a clean, representative transmission-fluid sample; use the specified tests when viscosity, wear metals, contaminants, or remaining service life must be assessed.
Confronto di modelli
Scegliere il metodo di prova dei fluidi più adatto
Guida al modello
Scegli uno o più modelli. AS505 è selezionato per impostazione predefinita.
1 modello selezionato
Non è stato selezionato alcun modello. Scegli un modello da confrontare.
| Nome prodotto | Tester per liquido freni AS501 | Tester per liquido freni AS502 | Tester di qualità dell'olio motore AS503 | Tester per fluidi di trasmissione AS505 | Tester per il punto di ebollizione del liquido freni AS506 | Tester per fluidi del servosterzo AS507 | Tester per il punto di ebollizione del liquido di raffreddamento AS509 |
|---|---|---|---|---|---|---|---|
| Metodo di prova e applicazione | |||||||
| Tecnologia di rilevamento | Tecnologia di rilevamento dell'aumento di pressione | Analisi del contenuto idrico; nessuna generazione o misurazione della pressione idraulica. | Tecnologia della sonda ottica | Tecnologia della sonda ottica | Esempio di tecnologia di riscaldamento | Tecnologia della sonda ottica | Esempio di tecnologia di riscaldamento |
| Principio di funzionamento | Liquido freni (contenuto di acqua) | Liquido freni (contenuto di acqua) | Olio motore (trasmittanza) | Fluido di trasmissione (trasmittanza) | Liquido freni (punto di ebollizione) | Fluido dello sterzo (trasmittanza) | Liquido di raffreddamento |
| Selezione della modalità di test | Modalità normale | Modalità normale/Modalità esperto | Motore a benzina/Motore diesel | Fluido per trasmissioni automobilistiche | Modalità normale/Modalità marca | Servosterzo automobilistico | Modalità normale/Modalità marca |
| Valore di riferimento del punto di ebollizione | × | × | × | × | ✓ | × | ✓ |
| Modalità normale | Tipi 6 ENV-4、ENV-6 DOT3, DOT4, DOT5, DOT5.1 | Tipi 3 DOT3, DOT4, DOT5.1 | × | × | DOT3, DOT4 e DOT5.1 (scelte confermate dalla procedura) | × | 23 marche di liquido refrigerante Per ACDELCO、BASF、BOSCH、CASTROL、ENGINE_ICE、EVANS、FORD、HONDA、JOHN_DEERE、KUNLUN、MOBIL、MOPAR、NISSAN、OMTECH、PEAK、PRESTON、RECOCHEM、SHELL、SKI-DOO、ZEREX、STAR_BRITE、TOTAL、TOYOTA |
| Misurazione e risposta | |||||||
| Commutazione dell'unità di temperatura | × | × | ℃ / ℉ | ℃ / ℉ | ℃ / ℉ | ℃ / ℉ | ℃ / ℉ |
| Intervallo di misurazione della temperatura | × | × | 0-85 ℃ 0-185 ℉ | 0-85 ℃ 0-185 ℉ | 0-320 ℃ 0-608 ℉ | 0-85 ℃ 0-185 ℉ | Intervallo di punto di ebollizione del liquido di raffreddamento diluito: 100 ° C ~ 120 ° C (212 ° F ~ 248 ° F) Intervallo di riferimento del punto di ebollizione del liquido di raffreddamento del produttore originale 106 ° C ~ 191 ° C (221 ° F ~ 376 ° F) |
| Durata del test | Risposta di 10 secondi | Risposta di 10 secondi | Risposta di 10 secondi | Risposta di 10 secondi | Risposta di 16 secondi | Risposta di 10 secondi | Risposta 20-40 secondi |
| Display, sonda e alimentazione | |||||||
| Schermo retroilluminato | 1.8 pollici | 2.8 pollici | 2.8 pollici | 2.8 pollici | 1.54 pollici | 2.8 pollici | 1.6 pollici |
| Lunghezza del cavo di prova | 26cm | 26cm | 80cm | 80cm | 4cm | 80cm | 130cm |
| Tensione di alimentazione | 3V | 6V | 6V | 6V | 12V | 6V | 10-14V |
| Materiale del tubo | Ossido di ferro | 304 in acciaio inox | Teflon | Teflon | × | Teflon | × |
Manuale e supporto
Trova il manuale e le linee guida per il test dei fluidi
AUTOOL Manuale utente AS505
Apri il manuale PDF per AUTOOL AS505 transmission-fluid testing, optical-probe use, temperature display, result interpretation, battery operation, probe cleaning and troubleshooting support.
Dotazione
Scopri cosa contiene la confezione
- Unità principaleAUTOOL AS505 transmission fluid tester with integrated 800mm probe
- Scatola al minutoAUTOOL AS505 product package box
- ArticoloManuale Utente AUTOOL AS505 user manual for setup, display, battery installation, operation, and warranty information
- CONFEZIONENote Accessories. Batteries are not listed in the package image, so prepare 4 × 1.5V AAA batteries if needed.
Domande degli acquirenti
Domande relative a fluidi, metodo e risultati
Cosa fa il AUTOOL Test AS505?
AS505 tests automotive transmission fluid transmittance and displays transmission fluid temperature. It helps users assess fluid clarity, possible contamination, deposits, and whether service attention may be needed.
Is AS505 An ATF Exchanger Or A Fluid Tester?
AS505 is a transmission fluid tester. It is used to check transmission fluid transmittance and temperature. It does not exchange, flush, drain, or refill transmission fluid.
How Often Should I Test Transmission Fluid With AS505?
It is recommended to test transmission fluid once every 5,000-10,000 km. Testing frequency can also depend on vehicle mileage, driving conditions, transmission behavior, and maintenance schedule.
How Do I Use The AS505?
Install batteries, power on the tester, wipe the probe clean, confirm the engine temperature is below 60°C, submerge the probe into transmission fluid, press the test button, and read the transmittance and temperature result on the LCD.
What Do OK, Warning, And Suggested Replacement Mean?
OK indicates transmittance is between 100% and 50%. Warning indicates transmittance is between 50% and 30%. Suggested replacement appears when transmittance is below 30%. Use these results as a service reference together with vehicle condition and workshop judgment.
Can AS505 Test Engine Oil, Brake Fluid, Or Power Steering Fluid?
AS505 is designed for automotive transmission fluid testing. For engine oil transmittance, choose AS503. For brake fluid water content, choose AS501 or AS502. For brake fluid boiling point, choose AS506. For power steering fluid transmittance, choose AS507.
What Temperature Conditions Should I Follow?
The tester operating temperature is -10°C-60°C. The transmission fluid temperature display supports 0-85°C / 0-185°F. Before measurement, the engine temperature should be below 60°C.
What Power Supply Does AS505 Use?
AS505 uses 6V power from 4 × 1.5V batteries. Open the rear battery cover, install the batteries with correct polarity, and close the cover securely before use.
What Is Included In The AS505 Package?
Package contents: AS505 main unit with built-in probe, retail box, and user manual.
Why Should The Probe Be Wiped Clean Before Testing?
The optical probe reads fluid transmittance. Oil residue, dirt, or contamination left on the probe may affect measurement feedback, so the probe should be wiped clean before each measurement.
Quanto dura la garanzia?
Unità principale: 3 anni di garanzia. Accessori standard: 1 anno di garanzia. Politica di garanzia.
Who Should I Contact For AS505 Setup Or Model Selection?
Contatti AUTOOL Store if you need help with AS505 setup, transmission fluid testing, result interpretation, package confirmation, or choosing between AS502, AS503, AS505, AS506, and AS507.
