AUTOOL Настенная зарядная станция для электромобилей C701 типа 2
US$489.00
Ключевые особенности
- 220 V / Up to 32 A
- 8 m Oxygen-Free-Copper Cable
- 4.3-дюймовый сенсорный экран
- Card, Password + Plug-and-Play
- 220 V / Up to 32 A: Set 10, 14, 16, 25, or 32 A for the 220 V configuration; match the setting to the installed circuit and vehicle.
- 8 m Oxygen-Free-Copper Cable: Reach wall- or post-mounted parking positions with the 8 m oxygen-free-copper cable.
- 4.3-дюймовый сенсорный экран: View charging progress, current, voltage, temperature, power, and status on the 4.3-inch touchscreen.
- Card, Password + Plug-and-Play: Unlock charging by card, password, or plug-and-play mode.
- Scheduled Charging Control: Set a delayed charging window from the screen or supported app to align charging with a chosen tariff or site-load plan.
☰ ЗАПРОСИТЬ ОПТОВОЕ ПРЕДЛОЖЕНИЕ / B2BОфициальный запрос на коммерческое предложение
Форма запроса на загрузку...
- 3-летнюю гарантию Основной блок: 3 года · Аксессуары: 1 год
- 90-Day Returns Возврат возможен в течение 90 дней.
- Официальный магазин Оригинальная продукция · Прямая поддержка
AUTOOL C701 · Adjustable Wall-Mounted EV Charger with 8 m Cable
Schedule Home Charging with Local Access Control
Set up a fixed home charging point with an 8 m cable, 4.3-inch touchscreen, scheduled charging, and card, password, or plug-and-play access. Adjustable output helps match the installed circuit and vehicle, while supported app, Wi-Fi, and Bluetooth controls depend on the ordered hardware and regional service.
- 8 m Vehicle Cable
- 4.3 in Touchscreen
- Запланированная зарядка
- Card / Password / Plug-and-Play
- App / Wi-Fi / Bluetooth by Configuration
Ключевые особенности
Control Home EV Charging with Touchscreen, App, and Three Access Modes
Adjustable Wall Charging
C701 provides 7 kW AC charging at 220 V and 32 A. Match the charging current to the installed circuit and vehicle.
4.3-дюймовый сенсорный экран
The smart touchscreen clearly displays charging progress, current, voltage, temperature, power, and charging status during operation.
App And Local Connectivity
Use the supported app, Wi-Fi, or Bluetooth functions on the matching C701 hardware to view charging status and configure available charging options. Screen and local access controls remain available at the unit.
Three Unlocking Methods
Card, password, and plug-and-play unlocking support shared, security-focused, and quick daily charging scenarios.
8m Pure Copper Cable
The 8 m / 26 ft oxygen-free copper charging cable uses a thickened outer sheath for stable conductivity, durability, and flexible positioning in wall- or post-mounted installations.
Charging Protection Functions
C701 lists overvoltage, undervoltage, short-circuit, leakage, grounding, overcurrent, overtemperature, moisture, reverse-connection, waterproof, lightning, emergency-stop, and flame-retardant protection provisions.
These provisions support charging safety only when the exact unit is installed on a correctly rated, grounded circuit with the required upstream protection.
Check connector insulation and the emergency-stop function as directed in the manual for your C701 version.
Component-Specific Ingress Ratings
The C701 manual lists IP65 for the control box and IP54 for the vehicle connector when coupled. Installation and cable storage must preserve those conditions.
Confirm The Vehicle Connector
Order the vehicle connector and electrical version specified for the vehicle and region; match the complete connector standard rather than pin count alone.
Широкий температурный диапазон
Supports operation from -20°C to 50°C, helping adapt to very cold or hot environments.
Insulated Charging Connector
The connector design supports leakage protection, insulation, and flame-retardant protection.
Regional Documentation Check
Match the exact ordered electrical and connector configuration to the declarations and installation requirements for the destination market.
Расписание зарядки
Set a delayed start to place the charging session inside the household’s chosen tariff or load window.
The available saving depends on the electricity plan, installed system, selected current, and vehicle charging schedule.
7 kW Level 2 Home Charging Station
C701 provides up to 7KW rated power for faster home EV charging than standard low-power charging, making it suitable for regular household and workshop charging needs.
Документы соответствия
For FCC, CE, RoHS, or LVD documentation, ask AUTOOL which documents apply to the selected C701 configuration and market.
Adjustable Charging Range
The listed 10 A, 14 A, 16 A, 25 A and 32 A settings correspond to approximately 2.0–7 kW, subject to the ordered version and circuit capacity.
Гарантийное обслуживание в течение 3 лет
Основной блок: 3-летняя гарантия. Стандартные аксессуары: 1-летняя гарантия. Гарантийные условия.
Как использовать
Connect, Set and Monitor the Charge
Шаг вперед1 / 5
01
Confirm The Installation
Have a qualified person confirm supply voltage, circuit capacity, grounding, upstream protection, cable route, mounting location, regional requirements, and vehicle connector before installation.
02
Mount And Commission
Install the backplate and charging station as directed in the C701 manual, connect the dedicated supply, and complete the required electrical checks before energizing.
03
Choose Access And Current
Select card, password, or plug-and-play access and set an allowed charging current that matches the installed circuit and vehicle. Screen current selection is unavailable when the current is set by the JP2 jumper.
04
Connect And Monitor
Insert the vehicle connector fully, begin the session, and monitor status, current, voltage, temperature, power, and time on the display or supported app.
05
Finish And Inspect
End the session normally, return the connector to safe storage, and inspect the cable, connector, mounting, emergency stop, and displayed fault status regularly.
Безопасность и совместимость
Match the Circuit, Plug and Vehicle Connector
Место установки
Select a spot near the parking space for easy access to the power supply and keep the charger away from flammable objects.
Требования к питанию
Ensure the home circuit can handle the charging load. Hire a professional electrician to upgrade the wiring if needed.
Соответствующая требованиям установка
Follow local electrical and building codes so the charging station is installed in accordance with applicable regulations.
Match the Power Supply and Connector
Confirm the regional input, 220 V supply configuration, vehicle connector, current settings, matching manual, and required conformity documents before installation.
Protect Each Component
The control box is rated IP65 and the vehicle connector IP54 when coupled. Mount, connect, store, and inspect each part within those conditions.
Характеристики
Current, Cable and Protection Details
C350
C350 — 8–16 A / 3.3 kW / Portable
C701
C701 — 10–32 A / 7 kW / Wall-mounted
| Параметр | Значение |
|---|---|
| Установка | Wall-mounted AC charging station |
| Номинальный вход | AC 220 V ±20%, 50 Hz; confirm ordered regional version |
| Rated Current / Power | 32 A / 7 kW manual configuration; actual output is limited by installation and vehicle |
| Длина кабеля | 8 м |
| Control Box Rating | IP65 |
| Номинальные характеристики разъема | IP54 when coupled |
| Рабочая Температура | От -20 до 50 ° C |
| Высота установки | Ниже 2000 м |
Руководство и поддержка
Confirm Installation, Plug and Vehicle Fit
AUTOOL C701 Руководство пользователя
Open the PDF manual for C701 installation, circuit matching, scheduled charging and access controls, with charging safety and troubleshooting support.
Комплектация
Check Cable, Plug and Mounting Parts
- Зарядные станцииAUTOOL C701 wall-mounted charging station with attached charging cable.
- Монтажные деталиWall mounting bracket, screws, and expansion tubes.
- Карты доступаCards for the supported card-unlock mode.
- Руководство пользователяAUTOOL C701 installation and operating manual.
- Включенные компонентыReview the package image before ordering. This is the most complete packing-list image and shows the main charger, mounting accessories, user manual, wall mounting bracket, and access cards. ·
- Монтажные принадлежностиScrews and expansion tubes
- Поддержка монтажаКронштейн для настенного монтажа
- ДокументацияРуководство пользователя
Часто задаваемые вопросы (FAQ)
Connector, Circuit and Charging Questions
What Power Supply Does C701 Require?
The C701 manual lists an AC 220 V ±20%, 50 Hz, 32 A, 7 kW configuration. Have the ordered regional version, circuit capacity, grounding, and upstream protection confirmed before installation.
Do I Need A Professional Electrician To Install It?
Yes. A professional electrician is recommended, especially if the home circuit needs to be checked or upgraded. Installation should follow local electrical and building codes.
Can I Adjust The Charging Current?
Yes. The touchscreen offers 10, 14, 16, 25, and 32 A settings for the 220 V configuration. Select a current within the installed circuit and vehicle limits. If JP2 sets the current, touchscreen current selection is unavailable.
Does C701 Support Scheduled Charging?
Yes. C701 supports scheduled charging, allowing users to charge during lower-cost off-peak hours when the installation and electricity plan support this use case.
What Unlocking Methods Does C701 Support?
C701 supports card unlocking, password unlocking, and plug-and-play unlocking. These methods can support shared charging, enhanced security, or quick daily charging.
Is C701 Waterproof?
The manual lists IP65 for the control box and IP54 for the connector when coupled. Proper mounting, connection, cable storage, drainage, inspection, and maintenance are still required.
How Long Is The Charging Cable?
The charging cable is 8m / 26ft, providing more flexible reach for home garage and parking-space installation.
Which Vehicles Are Compatible?
C701 is designed for EVs compliant with IEC 62196-2. The compatibility image references Tesla, Volkswagen, Volvo, Skoda, Audi, MG, Dacia, Fiat, Ford, BMW, Mercedes-Benz and more. Always confirm the charging interface and regional voltage version before ordering.
Compatibility depends on the ordered vehicle connector, regional electrical version, vehicle inlet, onboard charger, and installation. Confirm the exact vehicle and connector rather than relying on a brand list.
What Is The Difference Between C350 And C701?
C350 is a lower-power portable option with 5m cable, 3.3KW rated power, IP65 protection, and 8A / 10A / 12A / 14A / 16A current levels. C701 is a wall-mounted 7KW charging station with 8m cable, 4.3-inch touchscreen, IP65 control box and IP54 vehicle connector when coupled as listed in the C701 manual, Bluetooth remote control, and 10A / 14A / 16A / 25A / 32A current levels.
C350 is a portable unit with a 5 m cable, five selectable current settings up to 16 A, and a delayed-start timer. C701 is a wall-mounted station with an 8 m cable, touchscreen, local access modes, and app connectivity. Confirm the exact C701 current configuration, connector, installation, and regional documents before choosing.
Как долго гарантия?
Основной блок: 3-летняя гарантия. Стандартные аксессуары: 1-летняя гарантия. Гарантийные условия.
