AUTOOL ATF702 Semi-Automatic Transmission Fluid Exchanger
US$1,099.00
주요 특징
- Semi-Automatic Valve Control
- Adjustable ATF Pressure + Flow
- ATF Exchange, Flush, Fill + Recovery
- 20 L Tank + Fluid Windows
- Semi-Automatic Valve Control: Manage ATF exchange directly through clearly identified mechanical valve positions and service controls.
- Adjustable ATF Pressure + Flow: Set pressure and flow to match the connected transmission service requirements.
- ATF Exchange, Flush, Fill + Recovery: Control ATF exchange, circulating flushing, filling, recovery, and draining of new and used tanks.
- 20 L Tank + Fluid Windows: Use the 20 L fluid tank and compare used and new ATF through separate windows while monitoring the exchange.
- 12 V Mobile Cabinet: Run from a fully charged 12 V DC battery and move the wheeled cabinet around the workshop.
- 3 - 년 보증 본체 3년, 부속품 1년
- 90- 일 반품 90일 이내 반품 가능
- 공식 스토어 정품 · 직접 지원
AUTOOL ATF702 · 12V Mechanical ATF Exchanger
Run a Mechanical ATF Exchange Step by Step
Run automatic-transmission fluid exchange through direct mechanical valve control. ATF702 lets the operator set pressure and flow, watch used and fresh fluid through separate windows, and select exchange, circulation, filling, recovery, or tank-draining paths. A 12 V wheeled cabinet supports movement between workshop service bays.
- 12 V Semi-Automatic Exchange
- 20 L Fluid Tank
- Six Mechanical Fluid Paths
- Adjustable Pressure + Flow
- Separate New / Used Windows
주요 특징
Mechanical Control with Visible Fluid Paths
Quick ATF Exchange
With the unit connected through an approved route and flow balanced, circulating flushing and ATF exchange can take about 20 minutes, with exchange efficiency approaching 100% under suitable conditions. Actual time and exchanged proportion depend on adapter setup, the vehicle circuit, fluid condition and the final-level procedure.
Manual Circulating Flushing
Manual circulation lets the operator move fluid through the connected service route before the exchange sequence.
Separate Used and New ATF Windows
Separate windows let technicians compare the condition of used ATF with new ATF during the exchange.
압력 및 유량 제어
Adjustable pressure and flow controls let technicians match the exchange to the vehicle’s service requirements and help reduce overfilling or underfilling risk while they monitor the connected process.
Easy-to-Identify Mechanical Controls
Clearly defined valve positions, pressure gauges, an emergency stop, a start switch, and visible indicators keep the main service controls easy to identify.
이동하기 쉬움
A wheeled cabinet with a push handle, swivel casters, and one-way casters makes the unit easier to move around the workshop.
Six Mechanically Selected Fluid Paths
ATF702 provides mechanical valve modes for ATF exchange, flushing, filling, recovery, and draining the new and used fluid tanks.
12V Workshop Operation
ATF702 runs from a fully charged 12V DC battery for mechanically controlled transmission fluid service.
Transmission Service Connections
Specialized connectors and hoses support a range of transmission fluid line layouts. Confirm adapter fitment for the vehicle before service.
Traditional Draining Is Limited
A traditional drain-and-fill may remove only about 25% of the used transmission fluid, leaving contaminated fluid in the transmission and torque converter.
Residual Used ATF Can Contaminate New ATF
Metal debris and sludge can remain in the transmission and mix with new ATF, reducing the benefit of the service and leaving the replacement fluid contaminated.
Contaminated ATF Can Affect Driving
Contaminated transmission fluid can contribute to slow acceleration and shuddering or vibration during shifts. It may also contribute to overheating and higher fuel consumption.
Control Pressure, Flow, and Fluid Condition
Incorrect filling or valve control can lead to overfilling or underfilling. ATF702 lets technicians monitor fluid pressure, flow, and color throughout the service.
Equal-Volume Exchange
Use this mode to exchange used ATF for new ATF while monitoring the fluid windows and tank levels.
Add New ATF to the Transmission
Use this mode to add new ATF after service or when the fluid level needs adjustment.
Circulating Flushing
Use this mode to run circulating flushing before the final ATF exchange, following the service procedure.
Recover ATF from the Transmission
Use this mode to recover transmission fluid from the vehicle when required by the service procedure.
Empty the New ATF Tank
Use this mode to drain remaining ATF from the new ATF tank when needed.
Empty the Used ATF Tank
Use this mode to empty the used ATF tank after service and prepare the machine for the next job.
3년 보증 지원
본체: 3년 보증. 표준 부속품: 1년 보증. 보증 정책.
서비스 워크플로
Connect, Exchange and Set Final Level
단계별 진행 상황1 / 7
01
Prepare Before First Use
Step 01 Before operation, check that all accessories are present and undamaged. Fill the new ATF tank with the specified new ATF. The ATF702 manual uses about 12 kg as an initial machine-fill starting point; prepare the actual fluid type and service quantity from the vehicle procedure. Keep the used-fluid container empty, and have the power cable, fluid lines, clear tube, adapters, and manual ready.
02
Fill the New ATF Tank from an External Container
Step 02 Place the clear connecting tube in the external container of new ATF. Set Valve 1 and Valve 2 to the positions specified for the required extraction or exchange mode, following the machine labels and user manual. Connect the power cable to a fully charged 12 V DC battery. Turn on the power switch to draw ATF from the external container.
03
Run Circulating Flushing
Step 03 Secure the vehicle before opening a transmission fluid line. Choose the correct adapters and confirm inlet and return flow. If the ATF702 manual and the vehicle procedure permit circulating flushing, follow the approved selector sequence and operating state. The machine manual uses about 5–10 seconds per position as an example; do not apply that dwell to every transmission.
04
Perform ATF Exchange and Final Checks
Step 04 Set the machine to exchange mode and monitor both tank levels, fluid windows, pressure, and transfer balance. Use only the selector positions and dwell allowed by the vehicle procedure. Restore the transmission fluid circuit, set the final level at the specified fluid temperature, engine state, and selector position, and inspect for leaks. Perform any permitted road check under the vehicle procedure; the manual’s about-1-km example is not a universal endpoint.
05
Shift Through the Gears During Service
During circulating flushing and ATF exchange, shift through the gears according to the user manual and vehicle-specific service procedure.
06
유체 레벨 확인
After reconnecting the transmission fluid line, restart the engine, shift to Park (P), check the transmission fluid level, and add fluid if needed.
07
Perform Final Inspection
Inspect all fluid lines and connections for leaks. When the machine’s procedure is suitable for the vehicle, drive about 1 km, then inspect the system again.
안전한 사용
Control Flow, Routing and Vehicle State
Use 12 V DC Power
Connect the power cable to a fully charged 12 V DC battery before operation.
Prepare New ATF
Before first use, fill the new ATF tank with new ATF. For the initial fill, use about 12 kg of new ATF as a starting amount.
Keep the Used ATF Container Empty
Keep the used ATF collection container (bottle or tank) empty before starting service.
Secure and Lift the Vehicle
Make sure the vehicle is securely braked and lifted before disconnecting or reconnecting transmission fluid lines.
Confirm ATF Flow Direction
Start the engine briefly only as needed to identify the ATF flow direction (inlet/outlet) before making the final line connection.
Allow Enough Flushing Time
When required by the service procedure, continue circulating flushing for more than 20 minutes.
Keep the Engine Running During Circulating Flushing
During circulating flushing, keep the engine running and shift through the gears as required by the user manual and vehicle-specific service procedure.
Follow Vehicle-Specific Higher-Speed Gear Procedures
If a vehicle-specific procedure requires higher-speed gear operation during fluid circulation, follow that procedure along with the user manual and workshop safety rules. Do not apply one speed to every vehicle.
결과 안내
Verify Flow, Level and Leak-Free Reconnection
결과를 확인하세요
Use the fluid windows as a process aid, then restore the circuit, set the final fluid level by the vehicle procedure and inspect for leaks.
모델 비교
Choose the Right ATF Exchanger
모델 가이드
Choose one or more models. ATF702 is selected by default.
1개 모델이 선택되었습니다.
선택된 모델이 없습니다. 비교할 모델을 선택하세요.
| 제품 모델 | ATF702 | ATF705 | ATF802 | ATF805 |
|---|---|---|---|---|
| Core Exchange & Automation | ||||
| 운전 방식 | 기계적 제어 | 전자 제어 | 전자 제어 | 전자 제어 |
| 운영 가이드 | × | ✓ | ✓ | ✓ |
| 스마트 익스체인지 | × | ✓ | ✓ | ✓ |
| Smart Cleaning Exchange | × | × | × | ✓ |
| Automatic Identification of Oil Inlet and Outlet | × | ✓ | ✓ | ✓ |
| Pipeline Self-Flushing | × | ✓ | ✓ | ✓ |
| Circulating Flushing | Manual | Manual | Automatic | Automatic |
| Circulating Oil Exchange (Equal Volume Exchange) | Manual | Automatic | Automatic | Automatic |
| New Oil Refilling | Manual | Automatic | Automatic | Automatic |
| 사용된 오일 회수 | Manual | Automatic | Automatic | Automatic |
| New Oil Tank Emptying | Manual | Automatic | Automatic | Automatic |
| Old Oil Tank Emptying | Manual | Automatic | Automatic | Automatic |
| New Oil Tank Electric Refilling | Manual | Manual | Automatic | Automatic |
| Power & Physical Setup | ||||
| 전원 공급 장치 | DC12V | Match the selected power configuration | 110V / 220V | 110V / 220V |
| 최대 전력 | ||||
| 노이즈 | ||||
| 오일 탱크 | 20L | 20L | 20L | 20L |
| 순 무게 | 45.8KG | 47KG | 53KG | 56KG |
| 총 중량 | 54.2KG | 59.5KG | 77.5KG | 82KG |
| Oil Exchange Hose | 2.5m | 2.5m | 2.5m | 2.5m |
| Oil Drain Hose | × | 1.5m | 1.5m | 1.5m |
| 전원 코드 | 3m | 3m | 3m | 3m |
| Fluid Control & Visibility | ||||
| 오일 펌프 | 단일 오일 펌프 | 단일 오일 펌프 | Dual Oil Pump | Dual Oil Pump |
| 압력계 | 2 Mechanical Pressure Gauge 10kg / cm² | 1 Mechanical Pressure Gauge 10kg / cm² | 2 Mechanical Pressure Gauge 10kg / cm² | 전자 10kg / cm² |
| New Fluid Heating | × | × | × | ✓ |
| Oil Temperature Display | × | × | × | ✓ |
| Oil Filter and Replacement Reminder | No Replacement Reminder | No Replacement Reminder | ✓ | ✓ |
| Real-Time Display of Oil Tank Level | × | ✓ | ✓ | ✓ |
| Oil Exchange Window | ✓ | ✓ | ✓ | ✓ |
| Liquid Level Window | ✓ | ✓ | ✓ | ✓ |
| 샘플링 창 | × | × | × | ✓ |
| Oil Exchange Window Backlight | × | ✓ | ✓ | ✓ |
| Liquid Level Window Backlight | ✓ | ✓ | ✓ | ✓ |
| Interface, Records & Software | ||||
| 화면 | × | 5 인치 IPS 화면 | 5 인치 IPS 화면 | 7 인치 IPS 화면 |
| 데이터 인쇄 | × | × | × | ✓ |
| 부저 알림 | × | ✓ | ✓ | ✓ |
| Data Entry Keyboard | × | × | × | ✓ |
| Oil Exchange Database | × | × | ✓ | ✓ |
| 시스템 업데이트 | × | × | USB 업데이트 | USB 업데이트 |
| 언어 설정 | × | Chinese, English, Spanish, French, German, Russian, Portuguese, Vietnamese, Malaysian | Chinese, English, Spanish, French, German, Russian, Portuguese, Vietnamese, Malaysian | Chinese, English, Spanish, French, German, Russian, Portuguese, Vietnamese, Malaysian |
사용 설명서 및 지원
Find the Manual and Fitment Guidance
AUTOOL ATF702 User Manual
PDF 설명서를 열어보세요 AUTOOL ATF702 mechanical ATF exchange, pressure and flow adjustment, circulation, filling and recovery paths, fluid compatibility, safety and troubleshooting support.
패키지 내용물
상자 안에 무엇이 들어 있는지 확인해 보세요
- 본체AUTOOL ATF702 semi-automatic ATF exchanger
- 어댑터 키트Transmission fluid line adapters and fittings
- 연결 관Clear connecting tube
- 사용 설명서AUTOOL ATF702 user manual
- 처음 사용하기 전에Check that all accessories are present and undamaged before operation
구매자 질문
ATF Setup, Fit and Service Questions
Why Do I Need an Automatic Transmission Fluid Exchanger?
Traditional draining may remove only part of the used ATF, while metal debris and sludge can remain in the transmission and contaminate new ATF. A transmission fluid exchanger can replace more of the used ATF for a more complete service.
How Long Does ATF702 Take to Change Transmission Fluid?
About 20 minutes under suitable service conditions. Actual time varies with the vehicle, fluid condition, flushing needs, adapter setup, and flow balance.
Is ATF702 Fully Automatic?
No. ATF702 is a semi-automatic transmission fluid exchanger with mechanical valve control and visible fluid windows. Choose ATF705, ATF802, or ATF805 if you need more electronic control or automated functions.
What Is the Difference Between ATF702 and ATF705?
ATF702 uses mechanical control, 12 V DC power, no screen, a single ATF pump, and manual circulating flushing. ATF705 adds electronic control and 110/220 V AC power, plus a 5-inch IPS screen. It also adds automatic equal-volume exchange and recovery, buzzer alerts, and real-time tank-level display.
What Power Supply Does ATF702 Use?
ATF702 uses 12 V DC power. Connect the power cable to a fully charged 12 V battery before operation.
How Much New ATF Should I Prepare?
Before first use, fill the new ATF tank with new ATF. Use about 12 kg as a starting amount. Keep the used ATF collection container (bottle or tank) empty. The exact amount should match the vehicle-specific service requirement.
Does ATF702 Support Circulating Flushing?
Yes. ATF702 supports manual circulating flushing using its mechanical valve controls. Keep the engine running and shift through the gears as required by the user manual and vehicle-specific service procedure. Monitor the used ATF window throughout the process.
How Do I Know the ATF Exchange Is Complete?
Use the new- and used-fluid windows to observe condition and flow, but do not use color alone as the completion criterion. Monitor transfer balance, restore the circuit, set the final level by the vehicle procedure, and inspect the reconnected lines for leaks.
What Should I Do If New ATF Flows More Slowly Than Used ATF?
If new ATF flows more slowly than used ATF, reduce the used ATF flow with the valve on the return line. Adjust the flow until used ATF output and new ATF input stay balanced.
Are Adapters Included With ATF702?
Yes. The package includes an adapter kit with transmission fluid line fittings, clamps, tubes, and related accessories. Package contents may vary by configuration, so confirm the adapter set included with your order.
What Should I Check After the ATF Exchange?
After the exchange, turn off the engine and reconnect the transmission fluid line. Restart the engine and complete the final fluid-level check at the temperature, engine state, and selector position specified for the vehicle. Add fluid if needed, inspect every opened connection for leaks, and perform the approximately 1 km road check from the ATF702 procedure when it is suitable for the vehicle, followed by a final inspection.
Can ATF702 Be Used for All Automatic Transmissions?
ATF702 includes specialized connectors for a range of automatic transmissions, but adapter fitment depends on the vehicle’s transmission fluid line layout. Confirm compatibility before service or contact support for adapter guidance.
How Long Is the Warranty?
본체: 3년 보증. 표준 부속품: 1년 보증. 보증 정책.
